Overview
High‑performance, Heavy-Duty, industrial safety projector for clear and durable projection of warning signs and safety symbols.
Technical Specifications
Power Options
450W | 600W
Color Temperature
7000K | 7500K
Housing
Aviation Grade Aluminum
Dimensions
650x330x360mm (450W) | 650x330x360mm (600W)
Protection
IP65
Light Distribution
SPOT 13° | SPOT 15° | MEDIUM 18° | MEDIUM 25° | MEDIUM 38° | WIDE 53°
Beam Spread & Projected Icon Diameter
| Beam Angle | 5m Distance | 8m Distance | 10m Distance | 20m Distance |
|---|---|---|---|---|
| 13° | Ø 1.14 m | Ø 1.82 m | Ø 2.28 m | Ø 4.56 m |
| 15° | Ø 1.32 m | Ø 2.11 m | Ø 2.64 m | Ø 5.28 m |
| 18° | Ø 1.59 m | Ø 2.54 m | Ø 3.18 m | Ø 6.36 m |
| 25° | Ø 2.22 m | Ø 3.55 m | Ø 4.43 m | Ø 8.86 m |
| 39° | Ø 3.54 m | Ø 5.66 m | Ø 7.07 m | Ø 14.14 m |
| 53° | Ø 5.00 m | Ø 7.99 m | Ø 9.99 m | Ø 19.98 m |
